Vibrating Rod Point Level Switch

blog_img
  •
  •
  • Vibrating Rod Point Level Switch
  •

Measuring Principle

When in air the sense rod is set into mechanical vibrations at its resonant frequency by Piezo elements. The Vibrations are damped when the rod gets covered with the service materials. πRock Electronics effectively excites the Piezo elements and detects the damping accurately to signal an alarm condition.


Applications

Materials like: Cement, powdered milk, flour, spices, coffee beans, coffee powder, tea, salt, sugar, grains, chocolate powder, tobacco, powdered cellulose, powdered clay, polystyrene powder, dry soot, soda ash, coal ash, gravel, glass fine powder, granular plastics, foundry sand, cements, plastic pellets, frozen potato chips, beans, peanuts, sweets & candy, animal/ pet food, wood shavings, chalk, Styrofoam’s, charcoals, etc.



Specifications :


Housing : SS316 Process Pressure : 16 bars
Probe length : 250mm to 2000mm Output Type : PNP Standard
Process Fitting : Threaded 1-1/2” BSP/NPT
Flanged 2” ANSI/ASA
Output : Max 100mA, Short-circuit protected
Process Temperature : Upto 150°C Standard ,200°C on request Input Supply : 12...30VDC (70mA max)
Also available in 90...265VAC.(separate model)
Ambient Temperature : -20°C to 60°C
