Percentage Level Indicator is used to know the level of liquid in storage or process tank. The unit consist of a Percentage Level Sensor mounted inside the tank & a Digital Level Indicator mounted in control room or pump room or user accessible area.
The Percentage Level Sensor is a Magnetic Float Operated Level Sensor with ten set point with each set point equal to 10% of the tank depth. The sensor gives variable resistance output from zero U to 2.5k U. for each set point the output resistance will increase by 250 U.
Digital Level Indicator is a microcontroller bases electronic unit for display of level in percentage. The level is displayed as 0%, 10%, 20%, 30%, 40%,…………80%, 90% & 100%. The display is through Seven Segment bright LED display. The unit is connected to Percentage Level Indicator supplied by us. Digital Level Indicator comes with a unique feature of Dual option of Pump control Or Alarm facility. The unit can be used to either switch ON & OFF the pump or provide High & Low Level Alarm by selecting suitable DIP Switch,
Auto / Manual selector switch is provided for manual intervention. Similarly Alarm is between Low & High Level which is field selectable between ten steps. Digital Level Indicator also provides optional 4-20mA output. It is very useful for Water Sumps, Overhead Tanks, Diesel Storage Tanks, Diesel Day Oil Tanks, Oil Tanks, Chemical Tanks, Storage Tanks Etc.
| Supply Voltage : | 95-280VAC, 50Hz |
| Power Consumption : | 3VA |
| Output : | 4-20mA / 0-10V DC |
| Outputs : | Pump Relay – 2NO Rated 5A@ 250V AC Resistive Load. |
| Facility Available : | Alarm Relay – 1C / O Rated 10A @ 250V AC Resistive Load. |
| Pump Relay Settings : | Analogue O/P – 0-10V DC/ 15mA. |
| Alarm Relay Settings : | Pump made / Drain mode (p / d) Programmable. High Level – 10 to 100% Programmable. Low Level – 0 to 90% Programmable. |
