We are ledaing Capitance Level Transmitter Manufacturers, Suppliers, Dealers in India|Sahana Engineering. We capacitance level manufacturers in India offer a standard variety of these transmitters made from high quality raw material which is best suited for measuring the level of liquids and favorable in nature for our clients.
Our Capacitance Level Transmitter manufacturers company in India creates them with innovative techniques having intrinsically safe design and frame proof enclosure and also remains unaffected by dust to withstand the expectations of our valuable clients.
CAPACITANCE LEVEL TRANSMITTER is the type of transmitter that operates like a capacitor. These capacitors consist of two conductive plates which are separated by the medium called as insulating material having
dielectric constant. The insulated electrode acts as the first plate and the other plate comprises a tank wall or reference electrode.
WORKING PRINCIPLE- Their working depends upon the principle of change of capacitance. The capacitance depends upon the variety of fluid level such as aqueous and organic liquids, solids, slurries, powders,
granular material, etc.
The output is 4-20mA, 4 wire connections for isolated supply & 3 wires for non isolated supply. 2 wire loop powered output is also available. The tank empty (4mA) & Full (20mA) calibration is through easy field calibration button in case of 4 wire & 3 wire. For 2 wires it is through multi turn trimpot. Rigid probe is offered for tank depth upto 3 mtr & Flexible probe upto 15mtr. Capacitance Level Transmitter is available with different mounting arrangement to suit customer requirement. It is widely used for water, diesel, oil and chemical application.
| Type | 2 Wire (Loop powered), 3 wire (isolated), 4 wire (Isolated) 4-20 mA 0-10 V DC |
| Input | 24V Dc |
| Permissible Load | 500Ω |
| Measuring Rage | 200 mm to 3000 mm in Rigid Probe Upto 15000 mm in Flexile Probe |
| Pressure Max. | 5kg / cm 2 |
| Temperature | -25 to 100oC |
| Enclosure | Die Cast aluminium, Weatherproof or Flameproof |
| Resolution | 5mm |
| Accuracy | +0.5 % Fs |
| Mounting | Threaded -½" / 1" / 2" bspm or Npt Flange - 1" /2" Asa/Ansi/Jis/din |
| Mounting | SS 304 or SS 316 |
| Range | 0 to 10 Meter |
| Design Pressure | Up to 15kg |
| Temperature | 85`C |
| Probe Material | SS304 PTFE insulated SS316 SS316L |
| Transmitter Output | 4-20 m-Ampere |
